2.92mm Male to 2.92mm Bulkhead Waterproof Female Gore CNX 3506 Test Cable Assemb
PN: CA3506-2.92M-2.92FBW-25cm-1477
PRODUCT OVERVIEW
Series: |
2.92mm male to 2.92mm Female for Gore3506 cable, DC to 40GHz, Test cable |
RoHS: |
Compliant |
DOWNLOADS
PRODUCT SPECIFICATIONS
Technical Data |
Impedance: |
50Ohm |
Frequency Range: |
0 ~ 40 GHz |
VSWR |
≤1.25 |
Temperature Range: |
-55 °C ~ +125 °C |
Weight: |
30g |
Durability (Matings): |
2.92mm male >500 |
2.92mm bulkhead female >500 |
|
|
Material Data |
Connector 1: 2.92mm Straight Male Solder for Gore CNX 3506 Cable [96-03-2M51-057] |
Piece Part |
Base Material |
Plating |
Center Contact: |
Beryllium Copper Alloy |
Gold-plated (Nickel underplated) |
Body: |
Stainless Steel (SU303) |
Passivated |
Insulator: |
PEI |
|
|
Connector 2: 2.92mm Bulkhead Waterproof Female Solder for Gore CNX 3506 [96-02-2D51-058] |
Piece Part |
Base Material |
Plating |
Center Contact: |
Beryllium Copper Alloy |
Gold-plated (Nickel underplated) |
Body: |
Stainless Steel (SU303) |
Passivated |
Insulator: |
PEI |
|
