SMB Male (Female Center Contact) to SMB Male (Female Center Contact) RG316 Cable
PN: CA316-SMBM-SMBM-1M-251
PRODUCT OVERVIEW
| Series: |
SMB Male to SMB Male for RG316 cable |
| RoHS: |
Compliant |
DOWNLOADS
PRODUCT SPECIFICATIONS
| Technical Data |
| Impedance: |
50Ohm |
| Frequency Range: |
0 ~ 3 GHz |
| Withstanding Voltage: |
≥250 V |
| Temperature Range: |
-55 °C ~ +125 °C |
| Weight: |
22.5g |
| Durability (Matings): |
SMB Male >500 |
| |
|
| Connectors: SMB Male Crimp for LMR100/RG174/RG316 Cable [P/N: 70-03-1M00-022] |
| Piece Part |
Base Material |
Plating |
| Center Contact: |
Phosphor Bronze |
Gold-plated (Nickel underplated) |
| Body: |
Brass & |
Gold-plated (Nickel underplated) |
| Outer Contact: |
Phosphor Bronze |
Gold-plated (Nickel underplated) |
| Insulator: |
PTFE |
|
