RF Coaxial Adapters

RP SMA Male to SMA Female RF Adapter

PN: A-SMAF-RPSMAM-081
A-081-001
A-081-002
PRODUCT OVERVIEW
Interface Type: SMA to RPSMA
Gender: SMA female to RPSMA male
RoHS: Compliant

DOWNLOADS
  • Customer Drawing [PDF]
  • 3D-Model [STP]
    • PRODUCT SPECIFICATIONS
    Technical Data
    Impedance: 50Ohm
    Frequency Range: 0 ~ 6 GHz
    Temperature Range: -65 °C ~ +165 °C
    Weight: 18g
    Durability (Matings): >500

    Material Data
    Piece Part Base Material Plating
    Center Contact: Phosphor Bronze Gold plating (Nickel underplated)
    Body: Brass Gold plating (Nickel underplated)
    Insulator: PTFE
