SMA female to BMA female 2 Hole flange adapter, DC to 22GHz
PRODUCT OVERVIEW
| Interface Type: |
BMA to SMA |
| Gender: |
BMA female to SMA female |
| RoHS: |
Compliant |
DOWNLOADS
PRODUCT SPECIFICATIONS
| Technical Data |
| Impedance: |
50Ohm |
| Frequency Range: |
0 ~ 22 GHz |
| VSWR |
1.30:1 |
| Temperature Range: |
-55 °C ~ +165 °C |
| Weight: |
20g |
| Durability (Matings): |
>500 |
| |
|
| Material Data |
| Piece Part |
Base Material |
Plating |
| Center Contact: |
Beryllium Copper Alloy |
Gold-plated (Nickel underplated) |
| Body: |
Brass |
Nickel plated |
| Insulator: |
PTFE |
|
