SMA Male to SMA Right Angle Male for HF141 blue FEP jacket Cable
PN: CA141HF-SMAM-SMARAM-100mm-2267
PRODUCT OVERVIEW
| Series: |
SMA Male to SMA RA Male connector for .141 Fep jacket cable, DC to 6GHz |
| RoHS: |
Compliant |
DOWNLOADS
PRODUCT SPECIFICATIONS
| Technical Data |
| Impedance: |
50Ohm |
| Frequency Range: |
0 ~ 6 GHz |
| VSWR |
≤1.30 |
| Temperature Range: |
-55 °C ~ +165 °C |
| Weight: |
25g |
| Durability (Matings): |
SMA male >500 |
| |
|
| Material Data |
| Connectors: SMA Male Connector Solder for RG402/.141 Cable [P/N: 60-03-2M06-180] |
| Piece Part |
Base Material |
Plating |
| Center Contact: |
Brass |
Gold-plated (Nickel underplated) |
| Body: |
Brass |
Gold-plated (Nickel underplated) |
| Coupling Nut: |
Brass |
Gold-plated (Nickel underplated) |
| Connectors: SMA Right Angle Male Connector Solder for RG402/.141 Cable [P/N: 60-13-2M06-221] |
| Piece Part |
Base Material |
Plating |
| Center Contact: |
Brass |
Gold-plated (Nickel underplated) |
| Body: |
Brass |
Gold-plated (Nickel underplated) |
| Coupling Nut: |
Brass |
Gold-plated (Nickel underplated) |
