3.5mm Female to N Male Clamp CTAL-520 Test Cable assembly, 1 Meter
PN: CA520AL-3.5F-NM-1M-2523
PRODUCT OVERVIEW
| Series: |
3.5mm female to Type N male for 520AL cable |
| RoHS: |
Compliant |
DOWNLOADS
PRODUCT SPECIFICATIONS
| Technical Data |
| Impedance: |
50Ohm |
| Frequency Range: |
0 ~ 18 GHz |
| VSWR |
≤1.30 |
| Temperature Range: |
-55 °C ~ +125 °C |
| Weight: |
110g |
| Durability (Matings): |
3.5mm female >500 |
| |
type N male >500 |
| |
|
| Material Data |
| 3.5mm Straight Female Solder for CTAL-520 Cable [PN: 99-02-2M66-018] |
| Piece Part |
Base Material |
Plating |
| Center Contact: |
Beryllium Copper Alloy |
Gold-plated (Nickel underplated) |
| Body: |
Stainless Steel (SU303) |
Passivated |
| Insulator: |
PEI |
|
|
N Straight Male Solder for CTAL-520 Cable [PN: 50-03-2M66-245]
|
| Piece Part |
Base Material |
Plating |
| Center Contact: |
Beryllium Copper Alloy |
Gold-plated (Nickel underplated) |
| Body: |
Stainless Steel (SU303) |
Passivated |
| Insulator: |
PTFE |
|
