MCX Straight Male Solder for .086/RG405 cable

PN: 30-03-2M11-004
30-03-2M11-004-2
PRODUCT OVERVIEW
Interface Type: MCX
Gender: Male
RoHS Certificate: Compliant
Interface Standards: IEC 61169

DOWNLOADS
PRODUCT SPECIFICATIONS
Technical Data
Impedance: 50Ohm
Frequency Range: ~ 6 GHz
Insulation Resistance: ≥1000MΩ
Voltage Rating 250 V rms
Cable entry center contact Soldered
Cable entry outer contact Soldered
Temperature Range: -65 °C ~ +165 °C
Weight: 2g
Durability (Matings): >500

Material Data
Piece Part Base Material Plating
Center Contact: Brass Gold plating (Nickel underplated)
Body: Brass Gold plating (Nickel underplated)
Insulator: PTFE
