PN: CA58-BNCM-TNCM-1.5M-404

Cable Assembly, BNC Straight Male to TNC Straight Male, RG58 Cable, 1.5 Meters
CA58-BNCM-TNCM-1
PRODUCT OVERVIEW
Series: BNC Male to TNC Male for RG58 cable
RoHS: Compliant

DOWNLOADS
PRODUCT SPECIFICATIONS
Technical Data
Impedance: 50Ohm
Frequency Range: ~ 3 GHz
Withstanding Voltage: ≥1000 V
Temperature Range: -20 °C ~ +80 °C
Weight: 84g
Durability (Matings): BNC Male >500
TNC Male >500

Material Data
Connector 1: BNC Straight Male Crimp for LMR195/RG58 Cable  [P/N: 10-03-1M18-003]
Piece Part Base Material Plating
Center Contact: Brass Gold-plated (Nickel underplated)
Body: Brass Nickel plated
Coupling Nut: Brass Nickel Plated
Insulator: PTFE

Connector 2: TNC Straight Male Crimp for LMR195/RG58 Cable  [P/N: 80-03-1M18-001]
Piece Part Base Material Plating
Center Contact: Brass Gold-plated (Nickel underplated)
Body: Brass Nickel plated
Fastening Nut:  Brass Nickel Plated
Insulator: PTFE
Gasket: Silicone Rubber
