MCX Bulkhead Female to None RG178 Cable Assembly, 20cm
PN: CA178-MCXFB-NONE-20cm-907
PRODUCT OVERVIEW
| Series: |
MCX Female for RG178 cable |
| RoHS: |
Compliant |
DOWNLOADS
PRODUCT SPECIFICATIONS
| Technical Data |
| Impedance: |
50Ohm |
| Frequency Range: |
0 ~ 3 GHz |
| Withstanding Voltage: |
≥250 V |
| Temperature Range: |
-50 °C ~ +155 °C |
| Weight: |
4g |
| Durability (Matings): |
MCX bulkhead female >500 |
| |
|
| Connector: MCX Straight Bulkhead Female Crimp for RG178 Cable [P/N: 30-02-1B12-026] |
| Piece Part |
Base Material |
Plating |
| Center Contact: |
Phosphor Bronze |
Gold-plated (Nickel underplated) |
| Body: |
Brass |
Gold-plated (Nickel underplated) |
| Insulator: |
PTFE |
|
