Waterproof Bulkhead Female to MMCX Right Angle Male Crimp RG178 Cable, 85.5mm
PN: CA178-SMAFBW-MMCXRAM-85.5mm-2008
PRODUCT OVERVIEW
| Series: |
SMA Bulkhead Female to MMCX Right Angle Male for RG178 |
| RoHS: |
Compliant |
DOWNLOADS
PRODUCT SPECIFICATIONS
| Technical Data |
| Impedance: |
50Ohm |
| Frequency Range: |
0 ~ 3 GHz |
| Withstanding Voltage: |
≥250 V |
| Temperature Range: |
-50 °C ~ +125 °C |
| Weight: |
12g |
| Durability (Matings): |
SMA Bulkhead Female >500 |
| MMCX Right Angle Male >500 |
| |
|
| Material Data |
| Connector : SMA Straight Waterproof Bulkhead Female Solder for RG178 Cable [P/N: 60-02-2B12-316] |
| Piece Part |
Base Material |
Plating |
| Center Contact: |
Beryllium Copper Alloy |
Gold-plated (Nickel underplated) |
| Body: |
Stainless steel(SUS316L) |
Passivated |
| Washer: |
Stainless steel(SUS316L) |
Passivated |
| Insulator: |
PTFE |
|
